Product Description
Replace a bent, damaged, or worn shift lever on your CSC RX3 with this direct replacement gear shift pedal. CSC part Z42-101 cross-references to Z21-107 and Zongshen OEM number 24400-D002-0072, also identified as the BT-72 shift pedal assembly.
This forged steel lever uses the original-style split clamp and pinch-bolt mounting design with an approximately 11 mm splined bore. The fixed toe peg includes a ribbed rubber cover for a positive contact surface when shifting.
- Fits: CSC RX3 / Zongshen ZS250GY-3
- CSC Part Number: Z42-101
- CSC Cross Reference: Z21-107
- Zongshen OEM: 24400-D002-0072
- Zongshen ERP: 100203972
- Design Reference: BT-72
- Spline Bore: Approximately 11 mm
- Mounting Style: Split splined clamp with pinch bolt
- Construction: Forged steel
- Finish: Silver
- Toe Peg: Fixed rubber-covered peg
- Spline Center to Toe Area: Approximately 160 mm
Additional cross-reference information: Zongshen 24400-D002-0072 is also documented in applications including the Xmotos XZ250R V4, Megelli 250R, and Zuumav K8 NC300. Honda XR650L-pattern shift levers have also been documented by RX3 owners as fitting the RX3 shift shaft, although lever length, bend, and offset may differ.
Fitment note: An 11 mm shift shaft alone does not guarantee compatibility. Compare the lever shape, offset, length, and clamp configuration with your original part before ordering for applications other than those specifically listed.
