Product Description
CSC RX3 Ignition Switch with 2 Keys - Z30-103
Replacement ignition/key switch for the CSC RX3. This factory-style assembly includes two keys, the mounting bracket, steering/fork-lock mechanism, attached wiring pigtail and a sealed 2-pin HM090-compatible male connector.
CSC RX3 Replacement Details
- CSC SKU: Z30-103
- 12V 2-wire SPST key-operated main-power switch
- 2 keys included
- 50 mm mounting-hole centers
- 6 mm mounting holes
- 68 mm maximum mounting-plate width
- Approx. 90 mm overall ignition assembly length
- Approx. 44 x 24 x 23 mm connector housing
- 2-pin sealed HM090-compatible male connector
Universal / Custom Applications
Because this is a simple 2-wire SPST switched-power key switch, it can also be useful for custom motorcycles and other 12V powersports applications when the wiring function and dimensions match. A matching HM090-compatible connector can be used, or the two-wire circuit may be adapted as appropriate for a custom harness.
Fitment note: For non-RX3 applications, compare the electrical function, connector, 50 mm mounting centers, 6 mm mounting holes, body size and steering-lock geometry before ordering.
